1. Small size, easy to carry and operate

2. 600V DC/AC voltage measurement

3. 400mA DC/AC current measurement

4. Resistance/Capacitance/Diode/Continuity test

5. Frequency/Duty cycle measurement

6. CE (EMC, LVD, RoHS), cETLus

7. CAT III 600V

8. 1m drop test

Спецификации Обхват Точност
DC Voltage 400mV~600V ±(0.5%+5)
AC Voltage 4V~600V ±(1.2%+5)
DC Current 400μA~400mA ±(1.8%+5)
AC Current 400μA~400mA ±(2.0%+8)
Resistance 400~40M ±(1.0%+5)
Capacitance 50nF~100μF ±(4%+10)
Frequency 10~60kHz ±(0.1%+5)
Duty Cycle 20%~80% For reference only
Свойства
NCV √
Diode Test √
Continuity Test √
Low Battery Indication √
Data Hold √
Auto Power Off √
Operation Temperature 0℃～50℃
Safety rating CAT III 600V
Основни характеристики
Product Color Red and grey
Product Net Weight 180g
Product Size 112 X 58 X 35mm
Standard Individual Packing Gift Box, Manual
