Свойства

● Sampling rate: 3 times/s
● True RMS
● Audible/visual alarm
● Capacitor charging indicator
● Ergonomic design
● Double injection molding
● Auto backlight
● Display count: 20000
● AC frequency range: 45~1000Hz
● Diode/continuity test
● Auto power off/auto backlight
● Индуктивност 200nS
● Data hold
● Function selection: SELECT

SpecificationsUT89XE
Safety ratings CAT II 1000V, CAT III 600V
DC voltage (V) 200mV/2V/20V/200V/1000V ±(0.05%+5)
AC voltage (V) 200mV/2V/20V/200V/1000V ±(0.8%+25)
DC current (A) 2000μA/200mA/20A ±(0.5%+4)
AC current (A) 2000uA/200mA/20A ±(1.5%+15)
Resistance () 200/2k/20k/200k/2M/20M/200M ±(0.4%+5)
Capacitance (F) 200mF ±(4%+50)
Индуктивност (ns) 200nS ±(1.2%+50)
Frequency (Hz) 60MHz ±(0.1%+3)
Temperature (℃)-40℃~1000℃ ±(1%+10)
Temperature (℉)-40℉~1832℉ ±(1.5%+10)
Audible/visual alarm V/A/Cap/Diode √
MAX/MIN√
Peak Hold√
Ниско-честотен филтър √
General Characteristics
Power 1.5V battery (R03) x 4
Display 61mm x 36mm
Product net weight 345g
Product size 189mm x 89mm x 53mm
Standard accessories Batteries, test lead, k-type temperature probe, English manual
Standard individual packing Gift box
